Universal Column (UC)

15 Reviews|In Stock

Standard: AS/NZS 3679.1

Grade: 300Plus

Universal Columns (UC) are structural steel sections with an H-shaped cross-section designed specifically for vertical load-bearing applications. They provide excellent compression strength and stability, making them ideal for building columns, posts, and structural supports. Our Universal Columns are manufactured to AS/NZS 3679.1 standards and are widely used in commercial, industrial, and residential construction projects.

Select Size

Selected Product Details:

  • Designation:250 UC 89.5
  • Weight:89.5 kg/m
  • Depth:260 mm
  • Flange Width:256 mm
  • Web Thickness:10.5 mm
  • Flange Thickness:17.3 mm
  • Surface Area:1.500 m²/m
  • Length:9m
Quantity

Universal Columns (UC), also known as H-columns or wide flange columns, are structural steel sections with an H-shaped cross-section designed specifically for vertical load-bearing applications. They are engineered to provide exceptional compression strength and stability while maintaining structural integrity under heavy loads.

Our Universal Columns are manufactured to AS/NZS 3679.1 standards using high-quality 300Plus grade steel. The H-shaped profile offers superior load distribution capabilities and excellent resistance to buckling, making them the preferred choice for building columns, structural posts, and load-bearing supports in construction projects of all scales.

Key Features:

  • Manufactured to AS/NZS 3679.1 standards for structural steel
  • 300Plus grade steel ensuring superior strength and durability
  • H-shaped cross-section optimized for compression loads
  • Excellent resistance to buckling and lateral-torsional buckling
  • Wide range of sizes from 100mm to 310mm depth
  • Superior load distribution capabilities
  • Available in primed or galvanised finishes
  • Standard and custom lengths to suit project requirements
  • Precision manufactured for consistent dimensional accuracy

Michael T.

Structural Engineer

"We've specified these 310UC columns for several high-rise projects and they consistently meet our structural requirements. The load-bearing capacity is excellent and the dimensional accuracy makes installation straightforward. The galvanised finish option is particularly useful for exposed applications. Great quality steel that meets Australian standards."

Posted 3 weeks ago

Jennifer K.

Construction Manager

"The 200UC series worked perfectly for our warehouse expansion project. Good strength-to-weight ratio and the columns arrived exactly to specification. Installation went smoothly and the structural integrity is solid. Only minor issue was delivery timing, but the quality makes up for it. Would definitely use again for future projects."

Posted 1 month ago
